Question #1

Scenario: More than 10,000 users will access a customer’s environment. The current networking infrastructure is capable of supporting the entire workforce of users. However, the number of support staff is limited, and management needs to ensure that they are capable of supporting the full user base.

Which business driver is prioritized, based on the customer’s requirements?

  • A . Simplify Management
  • B . Increase Scalability
  • C . Increase Flexibility
  • D . Reduce Costs
  • E . Enable Mobile Work Styles
  • F . Increase Security

Reveal Solution Hide Solution

Correct Answer: A
Question #2

Which three steps should a Citrix Architect complete to configure session settings for different user accounts or groups? (Choose three.)

  • A . Bind a profile to the authentication virtual server that handles the traffic to which the architect wants to apply the policy.
  • B . Create policies to select the connections to which to apply particular profiles and bind the policies to users or groups.
  • C . Create a profile for each user account or group for which the architect wants to configure custom session settings.
  • D . Customize the default settings for sessions with the global session settings.
  • E . Bind a policy to the authentication virtual server that handles the traffic to which the architect wants to apply the profile.

Reveal Solution Hide Solution

Correct Answer: B,C,E
Question #3

Scenario: A Citrix Architect has configured NetScaler Gateway integration with a XenApp environment to provide access to users from two domains: vendorlab.com and workslab.com. The Authentication method used is LDAP.

Which two steps are required to achieve Single Sign-on StoreFront using a single store? (Choose two.)

  • A . Configure Single sign-on domain in Session profile ‘userPrincipalName’.
  • B . Do NOT configure SSO Name attribute in LDAP Profile.
  • C . Do NOT configure sign-on domain in Session Profile.
  • D . Configure SSO Name attribute to ‘userPrincipalName’ in LDAP Profile.

Reveal Solution Hide Solution

Correct Answer: B,D
Question #4

Scenario: A Citrix Architect has met with a team of Workspacelab members for a design discussion They have captured the following requirements for the Citrix ADC design project:

The authentication must be deployed for the users from the workspacelab com and vendorlab com domains.

✑ The workspacelab users connecting from the internal (workspacelab) network should be authenticated using LDAP

✑ The workspacelab users connecting from the external network should be authenticated using LDAP and RADIUS.

✑ The vendorlab users should be authenticated using Active Directory Federation Service

✑ The user credentials must NOT be shared between workspacelab and vendorlab

✑ Single Sign-on must be performed between StoreFront and Citrix Gateway

✑ A domain drop down list must be provided if the user connects to the Citrix Gateway virtual server externally

Which method must the architect utilize for user management between the two domains?

  • A . Create a global catalog containing the objects of Vendorlab and Workspacelab domains.
  • B . Create shadow accounts for the users of the Vendorlab domain in the Workspacelab domain
  • C . Create a two-way trust between the Vendorlab and Workspacelab domains
  • D . Create shadow accounts for the users of the Workspacelab domain in the Vendorlab domain

Reveal Solution Hide Solution

Correct Answer: B
Question #5

Scenario: A Citrix Architect has deployed an authentication setup with a ShareFile load-balancing virtual server. The NetScaler is configured as the Service Provider and Portalguard server is utilized as the SAML Identity Provider. While performing the functional testing, the architect finds that after the users enter their credentials on the logon page provided by Portalguard, they get redirected back to the Netscaler Gateway page at uri /cgi/samlauth/ and receive the following error.

The events in the /var/log/ns.log at the time of this issue are as follows:

What should the architect change in the SAML action to resolve this issue?

  • A . Signature Algorithm to SHA 256
  • B . The Digest Method to SHA 256
  • C . The Digest Method to SHA 1
  • D . Signature Algorithm to SHA 1

Reveal Solution Hide Solution

Correct Answer: C
Question #6

Which parameter indicates the number of current users logged on to the Citrix gateway?

  • A . ICA connections
  • B . Total Connected Users
  • C . Active user session
  • D . Maximum User session

Reveal Solution Hide Solution

Correct Answer: C
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D

Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D

Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #7

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

✑ All three (3) Workspacelab sites (DC, NOR, and DR) will have similar Citrix ADC configurations and design.

✑ The external Citrix ADC MPX1 appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

✑ ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspacelab.com • In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

✑ On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

✑ On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Click the Exhibit button to view the logical representation of the network.

On which firewall should the architect configure the access policy to permit the MEP communication between the sites?

  • A . CISCO IPS 1 and Checkpoint FW1
  • B . CISCO IPS and CISCO IPS1
  • C . CISCO IPS and Checkpoint FW1
  • D . Checkpoint FW1 and DMZ ASA Firewall

Reveal Solution Hide Solution

Correct Answer: D
Question #28

Create service packages (Add OpenStack tenants)

Reveal Solution Hide Solution

Correct Answer: A

Explanation: –

Workflow to configure ADC instances using Heat


Question #29

Which IP address should be bound to VLAN 11?

  • A . 40.50.60.2
  • B . 192.168.30.2
  • C . 40.50.60.172
  • D . 192.168.20.170
  • E . 192.168.20.2
  • F . 192.168.30.171
  • G . 40.50.60.172

Reveal Solution Hide Solution

Correct Answer: E
Question #30

_________ content type supports sending NITRO commands to NetScaler. (Choose the correct option to complete sentence.)

  • A . Application/sgml
  • B . Text/html
  • C . Application/json
  • D . Text/enriched

Reveal Solution Hide Solution

Correct Answer: C

Question #31

Scenario: A Citrix Architect has deployed two MPX devices, 12.0.53.13 nc and MPX 11500 models, in a high availability (HA) pair for the Workspace labs team. The deployment method is two-arm. and the devices are installed behind a CISCO ASA 5585 firewall. The architect enables the following features on the Citrix ADC devices: Content Switching. SSL Offloading, Load Balancing, Citrix Gateway, Application Firewall in hybrid security, and Appflow. All are enabled to send monitoring information to Citrix Application Delivery Management 12.0.53.13 nc build. The architect is preparing to configure load balancing for Microsoft Exchange 2016 server.

The following requirements were discussed during the implementation:

✑ All traffic needs to be segregated based on applications, and the fewest number of IP addresses should be utilized during the configuration.

✑ All traffic should be secured, and any traffic coming into HTTP should be redirected to HTTPS.

✑ Single Sign-on should be created for Microsoft Outlook web access (OWA).

✑ Citrix ADC should recognize Uniform Resource Identifier (URI) and close the

session to Citrix ADC, when users hit the Logoff button in Microsoft Outlook web access.

✑ Users should be able to authenticate using user principal name (UPN).

✑ The Layer 7 monitor should be configured to monitor the Microsoft Outlook web access servers, and the monitor probes must be sent on SSL.

Which Responder policy can be utilized to redirect the users from http://mail.citrix.com to https://mail.citrix.com/owa?

  • A . add responder action Act redirect ""https://mail.citrix.com/owa/"" -responseStatusCode 302 add responder policy pol "http.REQ.URL.PATH_AND_QUERY.EQ("/")" Act
  • B . add responder action Act redirect ""https://mail.citrix.com/owa/"" -responseStatusCode 307 add responder policy pol "HTTP.REQ.IS_NOTVALID Act
  • C . add responder action Act redirect ""http://mail.citrix.com/owa/"" -responseStatusCode 302 add responder policy pol "HTTP.REQ.IS_NOTVALID Act
  • D . add responder action Act redirect ""http://mail.citrix.com/owa/"" -responseStatusCode 302 add responder policy pol "http.REQ.URL.PATH_AND_QUERY.EQ("/")" Act

Reveal Solution Hide Solution

Correct Answer: A
Question #32

Scenario: A Citrix Architect has set up NetScaler MPX devices in high availability mode with version 12.0.53.13 nc. These are placed behind a Cisco ASA 5505 Firewall. The Cisco ASA Firewall is configured to block traffic using access control lists. The network address translation (NAT) is also performed on the firewall.

The following requirements were captured by the architect during the discussion held as part of the NetScaler security implementation project with the customer’s security team:

The NetScaler MPX device:

✑ should monitor the rate of traffic either on a specific virtual entity or on the device. It should be able to mitigate the attacks from a hostile client sending a flood of requests. The NetScaler device should be able to stop the HTTP, TCP, and DNS based requests.

✑ needs to protect backend servers from overloading.

✑ needs to queue all the incoming requests on the virtual server level instead of the service level.

✑ should provide protection against well-known Windows exploits, virus-infected personal computers, centrally managed automated botnets, compromised webservers, known spammers/hackers, and phishing proxies.

✑ should provide flexibility to enforce the decided level of security check inspections for the requests originating from a specific geolocation database.

✑ should block the traffic based on a pre-determined header length, URL length, and cookie length. The device should ensure that characters such as a single straight quote (“); backslash (); and semicolon (;) are either blocked, transformed, or dropped while being sent to the backend server.

Which security feature should the architect configure to meet these requirements?

  • A . Global Server Load balancing with Dynamic RTT
  • B . Global Server Load Balancing with DNS views
  • C . Geolocation-based blocking using Application Firewall
  • D . geolocation-based blocking using Responder policies
  • E . Global Server Load Balancing with Mac Based Forwarding

Reveal Solution Hide Solution

Correct Answer: C
Question #33

A Citrix Architect can execute a configuration job using a DeployMasterConfiguration template on a Citrix ADC____deployed________. (Choose the correct option to complete sentence:

  • A . MPX; In high availability
  • B . CPX: without partitions
  • C . CPX; In high availability
  • D . MPX; as a cluster Instance
  • E . SDX; with more than 6 partitions

Reveal Solution Hide Solution

Correct Answer: A
Question #34

A Citrix Architect needs to make sure that maximum concurrent AAA user sessions are limited to 4000 as a security restriction.

Which authentication setting can the architect utilize to view the current configuration?

  • A . Global Session Settings
  • B . AAA Parameters
  • C . Active User Session
  • D . AAA Virtual Server

Reveal Solution Hide Solution

Correct Answer: A
Question #35

Scenario: A Citrix Architect needs to assess an existing on-premises NetScaler deployment which includes Advanced Endpoint Analysis scans. During a previous security audit, the team discovered that certain endpoint devices were able to perform unauthorized actions despite NOT meeting pre-established criteria.

The issue was isolated to several endpoint analysis (EPA) scan settings.

Click the Exhibit button to view the endpoint security requirements and configured EPA policy settings.

Which setting is preventing the security requirements of the organization from being met?

  • A . Item 3
  • B . Item 4
  • C . Item 2
  • D . Item 6

Reveal Solution Hide Solution

Correct Answer: D
Question #36

Which four settings can a Citrix Architect use to create a configuration job using Citrix Application Delivery Management? (Choose four.)

  • A . Action
  • B . File
  • C . Configuration Template
  • D . StyleBooks
  • E . Event Manager
  • F . Instance
  • G . Record and Play

Reveal Solution Hide Solution

Correct Answer: B,C,F,G
Question #37

Which response is returned by the Citrix ADC, if a negative response is present in the local cache?

  • A . NXDOMAIN
  • B . NXDATA
  • C . NODOMAIN
  • D . NO DATA

Reveal Solution Hide Solution

Correct Answer: A
Question #38

Which two NetScaler cookies indicate the validity of the Authentication, Authorization and Accounting (AAA) session for users? (Choose two.)

  • A . NSC_WT
  • B . NSC_TMAS
  • C . NSC_AAAC
  • D . NSC_TMAA

Reveal Solution Hide Solution

Correct Answer: B,D
Question #39

Which three methods can a Citrix Architect use to assess the capabilities of a network infrastructure? (Choose three.)

  • A . Review existing monitoring solutions for periods of latency, lost packets, and insufficient bandwidth.
  • B . Map the location of the users against the existing network topology.
  • C . Alter firewall rules of existing network to fit into the new NetScaler Deployment.
  • D . Examine the topology for single points of failure and potential bottlenecks.
  • E . Ensure that users and computers are in the correct organizational units (OUs).

Reveal Solution Hide Solution

Correct Answer: A,B,D
Question #40

Scenario: A Citrix Architect needs to assess an existing Citrix ADC configuration. The customer recently found that members of certain administrator groups were receiving permissions on the production Citrix ADC appliances that do NOT align with the designed security requirements.

Click the Exhibit button to view the configured command policies for the production Citrix ADC deployment.

To align the command policy configuration with the security requirements of the organization, the__________for________________should change. (Choose the correct option to complete the sentence.)

  • A . command spec; Item 6
  • B . priority; Item 5
  • C . command spec; Item 3
  • D . action; Item 4
  • E . priority; Item 2
  • F . action; Item 1

Reveal Solution Hide Solution

Correct Answer: E

Question #41

Which two settings must a Citrix Architect enable to deploy a shared VLAN on Citrix ADC VPX instance on an ESX platform? (Choose two.)

  • A . VLAN tagging on the VLAN
  • B . Port based VLAN tagging must be enabled
  • C . Promiscuous mode for shared VLANs
  • D . VLAN sharing on the VLAN

Reveal Solution Hide Solution

Correct Answer: C,D
Question #42

Scenario: A Citrix Architect and a team of Workspacelab members met to discuss a Citrix ADC design project.

They captured the following requirements from this design discussion:

• All three (3) Workspacelab sites (DC, NDR, and DR) will have similar Citrix ADC configurations and design.

• The external Citrix ADC MPX appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Active mode.

• ADNS service should be configured on the Citrix ADC to make it authoritative for domain nsg.workspaceIab.com.

• In GSLB deployment, the DNS resolution should be performed to connect the user to the site with least network latency.

• On the internal Citrix ADC, load balancing for StoreFront services, Citrix XML services, and Citrix Director services must be configured.

• On the external Citrix ADC, the Gateway virtual server must be configured in ICA proxy mode.

Which GSLB method should the architect utilize to meet the design requirements?

  • A . Dynamic RTT
  • B . Static Proximity
  • C . Least Bandwidth
  • D . Least Packets

Reveal Solution Hide Solution

Correct Answer: D
Question #43

Which StyleBook group should a Citrix Architect use to deploy the configuration for Microsoft SharePoint servers on Citrix ADC Management and Analytics (Citrix Application Delivery Management)?

  • A . Default
  • B . Public
  • C . Private
  • D . Custom

Reveal Solution Hide Solution

Correct Answer: A
Question #44

Scenario: A Citrix Architect needs to plan for a customer environment in which more than 10,000 users will need access. The networking infrastructure needs to be able to handle the expected usage.

Which business driver should be prioritized based on the customer’s requirement?

  • A . Increase flexibility
  • B . Enable mobile work styles
  • C . Simplify management
  • D . Increase Scalability
  • E . Reduce Costs
  • F . Increase Security

Reveal Solution Hide Solution

Correct Answer: A,E
Question #45

Scenario: A Citrix Architect has sent the following request to the NetScaler:

Which response would indicate the successful execution of the NITRO command?

  • A . 302
  • B . 201
  • C . 202
  • D . 200

Reveal Solution Hide Solution

Correct Answer: B
B

Explanation:

https://developer-docs.citrix.com/projects/netscaler-nitro-api/en/12.0/usecases/

Question #46

Which markup language can a Citrix use along with NITRO API to create a StyleBook?

  • A . GML
  • B . XML
  • C . HTML
  • D . YAML

Reveal Solution Hide Solution

Correct Answer: D
Question #47

Scenario: A Citrix Architect needs to configure a full VPN session profile to meet the following requirements:

✑ Users should be able to send the traffic only for the allowed networks through the VPN tunnel.

✑ Only the DNS requests ending with the configured DNS suffix workspacelab.com must be sent to NetScaler Gateway.

✑ If the DNS query does NOT contain a domain name, then DNS requests must be sent to NetScaler gateway.

Which settings will meet these requirements?

  • A . Split Tunnel to OFF, Split DNS Both
  • B . Split Tunnel to ON, Split DNS Local
  • C . Split Tunnel to OFF, Split DNS Remote
  • D . Split Tunnel to ON, Split DNS Remote

Reveal Solution Hide Solution

Correct Answer: D
D

Explanation:

https://support.citrix.com/article/CTX207149

Question #48

Scenario: The Workspacelab team has configured their NetScaler Management and Analytics (NMAS) environment. A Citrix Architect needs to log on to the NMAS to check the settings.

Which two authentication methods are supported to meet this requirement? (Choose two.)

  • A . Certificate
  • B . RADIUS
  • C . TACACS
  • D . Director
  • E . SAML
  • F . AAA

Reveal Solution Hide Solution

Correct Answer: B,C
Question #49

Which two settings should a Citrix Architect use on Citrix Application Delivery Management for configuring CPX using a pre-existing CPX device? (Choose two.)

  • A . Event Manager
  • B . instance
  • C . File
  • D . PIug and Play
  • E . Action

Reveal Solution Hide Solution

Correct Answer: B,C
Question #50

Scenario: A Citrix Architect needs to design a new Citrix Gateway deployment for a customer. During the design discussions, the architect documents the key requirements for the Citrix Gateway.

Click the Exhibit button to view the key requirements.

The architect should configure Citrix Gateway for __________________in order to meet the stated requirements. (Choose the correct option to complete the sentence.)

  • A . ICA proxy
  • B . Client access
  • C . VPN access
  • D . ROP proxy

Reveal Solution Hide Solution

Correct Answer: A

Question #51

Scenario: A Citrix Architect needs to design a new NetScaler Gateway deployment for a customer. During the design discussions, the architect learns that the customer would like to allow external RDP connections to internal Windows machines but does NOT want client drive redirection enabled on these connections.

Where should the architect enable the options to allow the customer to complete their requirement?

  • A . NetScaler Gateway global settings
  • B . RDP bookmark
  • C . Session policy
  • D . RDP server profile
  • E . Session profile
  • F . RDP client profile

Reveal Solution Hide Solution

Correct Answer: F
Question #52

Scenario: A Citrix Architect needs to design a hybrid XenApp and XenDesktop environment which will include Citrix Cloud as well as resource locations in an on-premises datacenter and Microsoft Azure.

Organizational details and requirements are as follows:

✑ Active XenApp and XenDesktop Service subscription

✑ No existing NetScaler deployment

✑ Global Server Load Balancing is used to direct connection requests to Location B, if the StoreFront server in Location B fails, connections should be directed to Location A.

Click the Exhibit button to view the conceptual environment architecture.

The architect should use _____ in Location A, and should use ________ in Location B. (Choose the correct option to complete the sentence.)

  • A . NetScaler ADC (BYO); NetScaler gateway appliance
  • B . NetScaler ADC (BYO); No NetScaler products
  • C . NetScaler ADC (BYO); NetScaler ADC (BYO)
  • D . NetScaler Gateway appliance; NetScaler Gateway appliance
  • E . NetScaler Gateway appliance; NetScaler ADC (BYO)

Reveal Solution Hide Solution

Correct Answer: B
Question #53

Scenario: A Citrix Architect needs to plan for a customer environment in which more than 10,000 users will need access. The networking infrastructure needs to be able to handle the expected usage.

Which business driver should be prioritized based on the customer’s requirement?

  • A . Increase flexibility
  • B . Enable mobile work styles
  • C . Simplify management
  • D . Increase Scalability
  • E . Reduce Costs
  • F . Increase Security

Reveal Solution Hide Solution

Correct Answer: D
Question #54

Scenario: The following NetScaler environment requirements were discussed during a design meeting between a Citrix Architect and the Workspacelab team:

✑ All traffic should be secured, and any traffic coming into HTTP should be redirected to HTTPS.

✑ Single Sign-on should be created for Microsoft Outlook web access (OWA).

✑ NetScaler should recognize Uniform Resource Identifier (URI) and close the session to NetScaler when users hit the Logoff button in Microsoft Outlook web access.

✑ Users should be able to authenticate using user principal name (UPN).

✑ The Layer 7 monitor should be configured to monitor the Microsoft Outlook web access servers and the monitor probes must be sent on SSL.

Which method can the architect use to redirect the user accessing https://mail.citrix.com to https://mail.citrix.com?

  • A . add responder action act redirect “https://mail.citrix.com” -responseStatusCode 302 add responder policy pol HTTP.REQ.IS_VALID act
  • B . add lb server test SSL 10.107.149.243.80 -persistenceType NONE -cltTimeout 180 – redirectFromPort 80 -httpsRedirectUrl https://mail.citrix.com
  • C . add lb server test SSL 10.107.149.243.443 CpersistenceType NONE -cltTimeout 180 – redirectFromPort 80 -httpsRedirectUrl https://mail.citrix.com
  • D . add responder action act redirect “https:// + HTTP
    REQ.HOSTNAME.HTTP_URL_SAFE +
    HTTP.REQ.URL_PATH_AND_QUERY.HTTP_URL_SAFE

    ” -responseStatusCode 302
    add responder policy pol HTTP.REQ.IS_VALID act

Reveal Solution Hide Solution

Correct Answer: C
Question #55

Scenario: A Citrix Architect needs to design a new NetScaler Gateway deployment to provide secure RDP access to backend Windows machines.

Click the Exhibit button to view additional requirements collected by the architect during the design discussions.

To meet the customer requirements, the architect should deploy the RDP proxy through ______ using a________ solution. (Choose the correct option to complete the sentence.)

  • A . CVPN: single gateway
  • B . CVPN, stateless gateway
  • C . ICAProxy: single gateway
  • D . ICAProxy; stateless gateway

Reveal Solution Hide Solution

Correct Answer: B
Question #56

Which four parameters can a Citrix Architect change after the initial creation of a session profile? (Choose four.)

  • A . Credential Index
  • B . Default Authorization Action
  • C . ICA Proxy Migration
  • D . Session Timeout
  • E . Expression
  • F . Name
  • G . Enable Persistent Cookie

Reveal Solution Hide Solution

Correct Answer: A,B,D,G
Question #57

Scenario: A Citrix Architect needs to design a new multi-datacenter Citrix ADC deployment. The customer wants Citrix ADC to provide access the various backend resources by using Global Server Load Balancing (GSLB) in an Active-Active deployment.

Click the Exhibit button to view additional requirements identified by the architect.

Which GSLB algorithm or method should the architect use for the deployment based on the stated requirements?

  • A . Source IP hash
  • B . Least response time
  • C . Least connections
  • D . Least packets
  • E . Static proximity
  • F . Dynamic round trip time (RTT)

Reveal Solution Hide Solution

Correct Answer: F
Question #58

Scenario: Based on a discussion between a Citrix Architect and a team of Workspacelab members, the MPX Logical layout for Workspacelab has been created across three (3) sites.

They captured the following requirements during the design discussion held for a Citrix ADC design project:

✑ All three (3) Workspacelab sites (DC NDR and DR) will have similar Citrix ADC configurations and design

✑ Both external and internal Citrix ADC MPX appliances will have Global Server Load Balancing (GSLB) configured and deployed in Active/Passive mode

✑ GSLB should resolve both A and AAA DNS queries.

✑ In the GSLB deployment the NDR site will act as backup for the DC site, whereas the DR site will act as backup for the NDR site

✑ When the external Citrix ADC replies to DNS traffic coming in through Cisco Firepower IPS the replies should be sent back through the same path

✑ On the internal Citrix ADC. both front-end VIP and back-end SNIP will be part of the same subnet

✑ USIP is configured on the DMZ Citrix ADC appliances

✑ The external Citrix ADC will act as default gateway for back-end servers.

✑ All three (3) sites (DC, NDR, and DR) will have two (2) links to the Internet from different service providers configured in Active/Standby mode

Which design decision must the architect make to meet the design requirements above?

  • A . Mac Based Routing must be configured on the External Citrix ADC
  • B . Interface 0/1 must be used for DNS traffic
  • C . The SNIP of the external Citrix ADC must be configured as default gateway on the back-
    end servers
  • D . ADNS service must be used with IPv6 address
  • E . The SNIP of the internal Citrix ADC must be configured as the default gateway on the back-end servers.

Reveal Solution Hide Solution

Correct Answer: E
Question #59

Scenario: A Citrix Architect needs to design a new multi-datacenter Citrix ADC deployment. The customer wants Citrix ADC to provide access to various backend resources by using Global Server Load Balancing (GSLB) in an Active-Active deployment. Click the Exhibit button to view additional requirements identified by the architect.

Which GSLB algorithm or method should the architect use for the deployment based on the stated requirements?

  • A . Dynamic round trip time (RTT)
  • B . Least response time
  • C . Least packets
  • D . Source IP hash
  • E . Static proximity
  • F . Least connections

Reveal Solution Hide Solution

Correct Answer: E
Question #60

Scenario: A Citrix Architect needs to assess a Citrix Gateway deployment that was recently completed by a customer and is currently in pre-production testing. The Citrix Gateway needs to use ICA proxy to provide access to a Citrix Virtual Apps and Citrix Virtual Desktops environment. During the assessment, the customer informs the architect that users are NOT able to launch published resources using the Gateway virtual server.

Click the Exhibit button to view the troubleshooting details collected by the customer.

What is the cause of this issue?

  • A . The Secure Ticket Authority (STA) servers are load balanced on the Citrix ADC.
  • B . The required ports have NOT been opened on the firewall between the Citrix Gateway and the Virtual Delivery Agent (VDA) machines
  • C . The StoreFront URL configured in the Citrix Gateway session profile is incorrect
  • D . The Citrix License Server is NOT reachable

Reveal Solution Hide Solution

Correct Answer: A

Question #61

Scenario: The Workspacelab team has implemented Citrix ADC high availability pair and Citrix ADC Management and Analytics System (Citrix Application Delivery Management). The Citrix Application Delivery Management was configured by a Citrix Architect to monitor and manage these devices. The Workspacelab team wants to load balance their Microsoft SharePoint servers on the Citrix ADC and needs the process to be streamlined and administered using Citrix Application Delivery Management.

The following requirements were discussed during the meeting:

✑ The Microsoft SharePoint server should be optimized, load balanced, and secured in the network and should be deployed using Citrix Application Delivery Management.

✑ All the configurations should be yenned before getting pushed to the Citrix

Application Delivery Management.

Which feature should the architect use to configure the Microsoft SharePoint server using Citrix Application Delivery Management?

  • A . StyleBooks
  • B . Orchestration
  • C . Configuration
  • D . Jobs Analytics

Reveal Solution Hide Solution

Correct Answer: A
Question #62

Which two features are supported on LbaaSV1? (Choose two.)

  • A . Cookie Insertion
  • B . Layer 7 Load Balancing
  • C . Certificate Bundle
  • D . Layer 4 Load balancing
  • E . Server name Indicator

Reveal Solution Hide Solution

Correct Answer: B,D
Question #63

Scenario: A Citrix Architect needs to design a new Citrix ADC Gateway deployment to provide secure RDP access to backend Windows machines.

Click the Exhibit button to view additional requirements collected by the architect during the design discussions.

To meet the customer requirements, the architect should deploy the RDP proxy through _______, using a _________ solution. (Choose the correct option to complete the sentence.)

  • A . ICAProxy, stateless gateway
  • B . CVPN; single gateway
  • C . CVPN; stateless gateway
  • D . ICAProxy; single gateway

Reveal Solution Hide Solution

Correct Answer: B
Question #64

Scenario: A Citrix Architect and a team of Workspacelab members have met for a design discussion about the NetScaler Design Project.

They captured the following requirements:

✑ Two pairs of NetScaler MPX appliances will be deployed in the DMZ network and the internal network.

✑ High availability will be accessible between the pair of NetScaler MPX appliances in the DMZ network.

✑ Multi-factor authentication must be configured for the NetScaler Gateway virtual server.

✑ The NetScaler Gateway virtual server is integrated with XenApp/XenDesktop environment.

✑ Load balancing must be deployed for the users from the workspacelab.com and vendorlab.com domains.

✑ The logon page must show the workspacelab logo.

✑ Certificate verification must be performed to identify and extract the username.

✑ The client certificate must have UserPrincipalName as a subject.

✑ All the managed workstations for the workspace users must have a client identifications certificate installed on it.

✑ The workspacelab users connecting from a managed workstation with a client certificate on it should be authenticated using LDAP.

✑ The workspacelab users connecting from a workstation without a client certificate should be authenticated using LDAP and RADIUS.

✑ The vendorlab users should be authenticated using Active Directory Federation Service.

✑ The user credentials must NOT be shared between workspacelab and vendorlab.

✑ Single Sign-on must be performed between StoreFront and NetScaler Gateway.

✑ A domain drop down list must be provided if the user connects to the NetScaler

Gateway virtual server externally.

✑ The domain of the user connecting externally must be identified using the domain selected from the domain drop down list.

On performing the deployment, the architect observes that users are always prompted with two-factor authentication when trying to assess externally from an unmanaged workstation.

Click the exhibit button to view the configuration.

What should the architect do to correct this configuration?

  • A . Update the binding LoginSchema Policy LDAP_RADIUS from the virtual server and set it as priority 1
  • B . Bind the Portal theme as Domaindropdown.
  • C . Bind the LoginSchema Policy Domaindropdown to priority 90.
  • D . Bind the Default LoginSchema Policy as Domaindropdown.

Reveal Solution Hide Solution

Correct Answer: A
Question #65

Which statement is applicable to Citrix Gateway split tunneling?

  • A . If you set split tunneling to reverse, the Citrix ADC Gateway plug-in sends only traffic destined for networks protected by Citrix ADC Gateway through the VPN tunnel. The Citrix ADC Gateway plug-in does NOT send network traffic destined for unprotected networks to Citrix ADC Gateway.
  • B . If you set split tunneling to reverse, the intranet applications define the network traffic that Citrix ADC Gateway does NOT intercept.
  • C . If you enable split tunneling, the intranet applications define the network traffic that Citrix ADC Gateway does NOT intercept.
  • D . If you enable split tunneling, the Citrix ADC Gateway plug-in captures all network traffic originating from a user device and sends the traffic through the VPN tunnel to Citrix ADC Gateway.
  • E . If you set split tunneling to reverse, the Citrix ADC Gateway plug-in captures all network traffic originating from a user device and sends the traffic through the VPN tunnel to Citrix ADC Gateway.

Reveal Solution Hide Solution

Correct Answer: B
Question #66

Under which two circumstances will a service be taken out of the slow start phase with automated slow start? (Choose two.)

  • A . The service does NOT receive traffic for three successive increment intervals.
  • B . The server request rate parameters are set above 25 requests per second.
  • C . The actual request rate is slower than the new service request rate.
  • D . The percentage of traffic that the new service must receive is greater or equal to 50.
  • E . The request rate has been incremented 100 times.

Reveal Solution Hide Solution

Correct Answer: A,C
Question #67

A Citrix Architect can execute a configuration job using a DeployMasterConfiguration template on a NetScaler_________deployed_________. (Choose the correct option to complete sentence.)

  • A . CPX; as part of a high availability pair
  • B . CPX; as a stand alone device
  • C . SDX; with less than 6 partitions and dedicated management interface
  • D . MPX; as part of the cluster but Cluster IP is NOT configured
  • E . SDX; with no partitions as a stand alone device

Reveal Solution Hide Solution

Correct Answer: C
Question #68

Which session parameter does the default authorization setting control when authentication, authorization, and auditing profiles are configured?

  • A . Determines the default logging level
  • B . Determines whether the NetScaler appliance will allow or deny access to content for which there is no specific authorization policy
  • C . Determines the default period after which the user is automatically disconnected and must authenticate again to access the intranet
  • D . Determines whether the NetScaler appliance will log users onto all web applications automatically after they authenticate or will pass users to the web application logon page to authenticate for each application.
  • E . Controls are amount of time the users can be idle before they are automatically disconnected.

Reveal Solution Hide Solution

Correct Answer: B
Question #69

Scenario: A Citrix Engineer is asked by management at the workspacelab organization to review their existing Citrix ADC Configurations and make the necessary upgrades. The architect recommends small changes to the pre-existing Citrix ADC configuration. Currently, the Citrix ADC MPX devices are configured in high-availability pair, and the outbound traffic is load balanced between two internet service providers (ISPs), however, the failover is NOT happening correctly.

The following requirements were discussed during the design requirement phase:

✑ The return traffic for a specific flow should be routed through the same path while using Link Load Balancing.

✑ The link should fail over even if the ISP router is up and intermediary devices to an ISP router are down.

✑ Traffic going through one ISP router should fail over to the secondary ISP, and the traffic should not flow through both routers simultaneously.

What should the architect configure with Link Load Balancing LLB) to meet the requirement?

  • A . Inverse NAT
  • B . Least packets load balancing method
  • C . Destination IP hash load balancing method
  • D . Reverse NAT.

Reveal Solution Hide Solution

Correct Answer: D
Question #70

Scenario: More than 10,000 users will access a customer’s environment. The current networking infrastructure is capable of supporting the entire workforce of users. However, the number of support staff is limited, and management needs to ensure that they are capable of supporting the full user base.

Which two business driver is prioritized, based on the customer’s requirements?

  • A . Simplify Management
  • B . Increase Scalability
  • C . Increase Flexibility
  • D . Reduce Costs
  • E . Enable Mobile Work Styles
  • F . Increase Security

Reveal Solution Hide Solution

Correct Answer: C,D

Question #71

Scenario: A Citrix Architect has deployed load balancing for SharePoint 2010 on a Citrix ADC instance.

While editing the document, the architect observed the error displayed below:

Sorry, we couldn’t open ‘https://sharepointcs.emea.in/Shared Documents/Citrix Enhancement Request Form.doc’

After troubleshooting, the architect discovers the issue. When a user opens a document, it opens in the browser, but while editing the document, thd session is transferred from the browser to the Word application During this time, the cookies should be transferred from the browser to the Word application.

Which two configurations should the architect modify to ensure that the cookies are shared between the browser and non-browser applications? (Choose two.)

  • A . Enable Persistent Cookie
  • B . Disable Persistent Cookie
  • C . Set HTTPOnly Cookie to NO
  • D . Set the NSC_AAAC cookie with HTTPOnly Flag
  • E . Set lb vserver -persistenceType COOKIEINSERT
  • F . Set HTTPOnly Cookie to Yes

Reveal Solution Hide Solution

Correct Answer: A,C
Question #72

Scenario: A Citrix Architect has set up NetScaler MPX devices in high availability mode with version 12.0. 53.13 nc. These are placed behind a Cisco ASA 5505 Firewall is configured to block traffic using access control lists. The network address translation (NAT) is also performed on the firewall.

The following requirements were captured by the architect during the discussion held as part of the NetScaler security implementation project with the customer’s security team:

The NetScaler device:

✑ Should monitor the rate of traffic either on a specific virtual entity or on the device. It should be able to mitigate the attacks from a hostile client sending a flood of requests. The NetScaler device should be able to stop the HTTP, TCP, and DNS based requests.

✑ Needs to protect backend servers from overloading.

✑ Needs to queue all the incoming requests on the virtual server level instead of the service level.

✑ Should provide access to resources on the basis of priority.

✑ Should provide protection against well-known Windows exploits, virus-infected personal computers, centrally managed automated botnets, compromised webservers, known spammers/hackers, and phishing proxies.

✑ Should provide flexibility to enforce the desired level of security check inspections for the requests originating from a specific geolocation database.

✑ Should block the traffic based on a pre-determined header length, URL length, and cookie length. The device should ensure that characters such as a single straight quote (*); backslash(), and semicolon (;) are either blocked, transformed, or dropped while being sent to the backend server.

Which two security features should the architect configure to meet these requirements? (Choose two.)

  • A . Pattern sets
  • B . Rate limiting
  • C . HTTP DDOS
  • D . Data sets
  • E . APPQOE

Reveal Solution Hide Solution

Correct Answer: B,E
Question #73

Scenario: A Citrix Architect needs to design a hybrid Citrix Virtual App and Citrix Virtual Desktop environment which will include as well as resource locations in an on-premises datacenter and Microsoft Azure.

Organizational details and requirements are as follows:

✑ Active Citrix Virtual App and Citrix Virtual Desktop Service subscription

✑ No existing Citrix deployment

✑ Minimization of additional costs

✑ All users should use same access point, regardless of network location

✑ No multi-factor authentication is required

Click the Exhibit button to view the conceptual environment architecture.

The architect should use___________ in Location A, and should use _______________ in Location B. (Choose the correct option to complete the sentence.)

  • A . No Citrix ADC products; Citrix ICA Proxy (cloud-licensed)
  • B . Citrix Gateway as a Service; Citrix ICA Proxy (cloud-licensed)
  • C . Citrix Gateway as a Service; no Citrix ADC products
  • D . No Citrix ADC products; Citrix Gateway appliance
  • E . Citrix gateway as a Service; Citrix ADC (BYO)
  • F . No Citrix ADC products; Citrix ADC (BYO)

Reveal Solution Hide Solution

Correct Answer: C
Question #74

Scenario: A Citrix Architect has implemented two high availability pairs of MPX 5500 and MPX 11500 devices respectively with 12.0.53.13 nc version. The NetScaler devices are set up to handle NetScaler Gateway, Load Balancing, Application Firewall, and Content Switching. The Workspacelab infrastructure is set up to be monitored with NMAS version 12.0.53.13 nc by the Workspacelab administrators. The Workspacelab team wants to implement one more pair of NetScaler MPX 7500 devices with version 12.0.53.13 nc.

The Citrix consulting team has assigned the task to implement these NetScaler devices in the infrastructure and set them up to be monitored and managed by NMAS.

The following are the requirements that were discussed during the project initiation call:

✑ NMAS should be configured to get the infrastructure information under sections such as HDX Insight, WEB Insight, and Security Insight.

✑ Configuration on the new MPX devices should be identical to MPX 11500 devices.

✑ Configuration changes after the deployment and initial setup should be optimized

using NMAS.

✑ NMAS should be utilized to configure templates that can be utilized by the Workspacelab team in future deployment.

✑ As per the requirement from the Workspacelab team, NMAS should be store the audited data for only 15 days.

Which process should the architect utilize to ensure that the deployment of MPX 11500 devices are optimized and that it is correct, before deploying the devices in production?

  • A . Under Stylebooks; Inbuilt and composite stylebook templates should be utilized prior to deployment.
  • B . Under Stylebooks; Public and composite stylebook templates should be utilized prior to deployment.
  • C . Under Configuration Management; Configuration Audit and Advice should be used prior to deployment.
  • D . Under Configuration jobs; Configuration Audit and Advice should be used prior to deployment.

Reveal Solution Hide Solution

Correct Answer: C
Question #75

Scenario: A Citrix Architect has deployed two MPX devices. 12.0.53.13 nc and MPX 11500 models, in a high availability (HA) pair for the Workspace labs team. The deployment method is two-arm and the devices are installed behind a CISCO ASA 5585 Firewall. The architect enabled the following features on the Citrix ADC devices. Content Switching. SSL Offloading, Load Balancing, Citrix Gateway. Application Firewall in hybrid security and Appflow. All are enabled to send monitoring information to Citrix Application Delivery Management 12.0.53.13 nc build. The architect is preparing to configure load balancing for Microsoft Exchange 2016 server.

The following requirements were discussed during the implementation:

✑ All traffic needs to be segregated based on applications, and the fewest number of IP addresses should be utilized during the configuration.

✑ All traffic should be secured and any traffic coming Into FITTP should be redirected to HTTPS.

✑ Single Sign-on should be created for Microsoft Outlook web access (OWA).

✑ Citrix ADC should recognize Uniform Resource Identifier (URI) and close the session to Citrix ADC when users hit the Logoff button In Microsoft Outlook web access.

✑ Users should be able to authenticate using either user principal name (UPN) or sAMAccountName.

✑ The Layer 7 monitor should be configured to monitor the Microsoft Outlook web access servers and the monitor probes must be sent on SSL.

Which monitor will meet these requirements?

  • A . add lb monitor mon.rpc HTTP-ECV -send "GET /rpc/healthcheck.htm" recv 200 -LRTM DISABLED -secure YES
  • B . add lb monitor mon.rpc HTTP -send "GET /rpc/healthcheck.htm" recv 200 -LRTM DISABLED -secure YES
  • C . add lb monitor mon.rpc HTTP-ECV -send "GET /owa/healthcheck.htm" recv 200 -LRTM DISABLED
  • D . add lb monitor mon.rpc HTTP-ECV -send "GET /owa/healthcheck.htm" recv 200 -LRTM ENABLED
  • E . add lb monitor mon.rpc HTTP-ECV -send "GET /rpc/healthcheck.htm" recv 200 -LRTM ENABLED

Reveal Solution Hide Solution

Correct Answer: A
Question #76

Scenario: A Citrix Architect and a team of Workspacelab members have met for a design discussion about the NetScaler Design Project.

They captured the following requirements:

✑ Two pairs of NetScaler MPX appliances will be deployed in the DMZ network and the internal network.

✑ High availability will be accessible between the pair of NetScaler MPX appliances in the DMZ network.

✑ Multi-factor authentication must be configured for the NetScaler Gateway virtual server.

✑ The NetScaler Gateway virtual server is integrated with XenApp/XenDesktop environment.

✑ Load balancing must be deployed for the users from the workspacelab.com and vendorlab.com domains.

✑ The logon page must show the workspacelab logo.

✑ Certificate verification must be performed to identify and extract the username.

✑ The client certificate must have UserPrincipalName as a subject.

✑ All the managed workstations for the workspace users must have a client identifications certificate installed on it.

✑ The workspacelab users connecting from a managed workstation with a client certificate on it should be authenticated using LDAP.

✑ The workspacelab users connecting from a workstation without a client certificate should be authenticated using LDAP and RADIUS.

✑ The vendorlab users should be authenticated using Active Directory Federation Service.

✑ The user credentials must NOT be shared between workspacelab and vendorlab.

✑ Single Sign-on must be performed between StoreFront and NetScaler Gateway.

✑ A domain drop down list must be provided if the user connects to the NetScaler

Gateway virtual server externally.

✑ The domain of the user connecting externally must be identified using the domain selected from the domain drop down list.

On performing the deployment, the architect observes that users are always prompted with two-factor authentication when trying to assess externally from an unmanaged workstation.

Click the exhibit button to view the configuration.

What should the architect do to correct this configuration?

  • A . Unbind LoginSchema Policy LDAP_RADIUS from the virtual server.
  • B . Bind the Portal theme as Domaindropdown.
  • C . Bind the LoginSchema Policy Domaindropdown to priority 90.
  • D . Bind the Default LoginSchema Policy as Domaindropdown.

Reveal Solution Hide Solution

Correct Answer: D
Question #77

Scenario: A Citrix Architect needs to assess a NetScaler Gateway deployment that was recently completed by a customer and is currently in pre-production testing. The NetScaler Gateway needs to use ICA proxy to provide access to a XenApp and XenDesktop environment. During the assessment, the customer informs the architect that users are NOT able to launch published resources using the Gateway virtual server.

Click the Exhibit button to view the troubleshooting details collected by the customer.

What is the cause of this issue?

  • A . The required ports have NOT been opened on the firewall between the NetScaler gateway and the Virtual Delivery Agent (VDA) machines.
  • B . The StoreFront URL configured in the NetScaler gateway session profile is incorrect.
  • C . The Citrix License Server is NOT reachable.
  • D . The Secure Ticket Authority (STA) servers are load balanced on the NetScaler.

Reveal Solution Hide Solution

Correct Answer: D
Question #78

Scenario: A Citrix Architect needs to design a NetScaler deployment in Microsoft Azure. An Active-Passive NetScaler VPX pair will provide load balancing for three distinct web applications.

The architect has identified the following requirements:

✑ Minimize deployment costs where possible.

✑ Provide dedicated bandwidth for each web application.

✑ Provide a different public IP address for each web application.

For this deployment, the architect should configure each NetScaler VPX machine to have ______ network interface(s) and configure IP address by using ________. (Choose the correct option to complete the sentence).

  • A . 4; Port Address Translation
  • B . 1; Network Address Translation
  • C . 1; Port Address Translation
  • D . 2; Network Address Translation
  • E . 4; Network Address Translation
  • F . 2; Port Address Translation

Reveal Solution Hide Solution

Correct Answer: C
Question #79

Which NetScaler Management and Analytics System (NMAS) utility can a Citrix Architect utilize to verify the configuration template created by the NMAS StyleBook, before actually executing it on the NetScaler?

  • A . Dry Run
  • B . configpack
  • C . NITRO API
  • D . configcheck

Reveal Solution Hide Solution

Correct Answer: A
Question #80

What can help a Citrix Architect prepare to discuss time scales and resource requirements?

  • A . Creating a high-level project plan.
  • B . Meeting with each member of the project team to assign tasks.
  • C . Designing the new environment.
  • D . Setting expectations with the project’s key stakeholders.
  • E . Identifying challenges associated with the project.

Reveal Solution Hide Solution

Correct Answer: A
Exit mobile version
