1. Refer to the exhibit.

An engineer is troubleshooting an OSPF issue. Router 1 has a neighbor relationship with router 2. Only router 1 classful EIGRP routes can be seen on router 2.

In order for all EIGRP routes to be redistributed correctly, which action should be taken?

Router 1 must have the keyword subnets included in the redistribution command for all EIGRP routes to be redistributed.

Router 1 must remove the AS number 1 from the redistribution command for all EIGRP routes to be redistributed.

Router 1 must have the keyword ospf-metric included in the redistribution command for all EIGRP routes to be redistributed.

Router 1 must have the keyword metric-type 1 included in the redistribution command for all EIGRP routes to be redistributed.

2. Refer to the exhibit.

R1 is directly connected to R2 and R3. R1 is in BGP AS 123, R2 is in BGP AS 2, and R3 is in BGP AS 3. Assume that there is no connectivity issue between R1, R2 and R1, R3.

Which result between BGP peers R1, R2 and R1, R3 is true?

The BGP session does not come up between R1 and R2 and between R1 and R3.

The BGP session comes up between R1 and R2 and between R1 and R3.

The BGP session comes up between R1 and R3, but not between R1 and R2.

The BGP session comes up between R1 and R2, but not between R1 and R3.

3. Refer to the exhibit.

An engineer is addressing an IS-IS design issue which is running within the topology. All links are running on FastEthernet, except the link between R5 and R4, which is Gigabit Ethernet.

Which statement about the design is true?

R4 prefer to reach R5 using R1 as the next hop

All links have equal cost if the default metric is used

R5 prefers to use R4 as the next hop for all routes

R1 prefer to use R5 as the next hop to reach R4

4. What is used by SR-TE to steer traffic through the network?

shortest path calculated by IGP

dynamic rules

path policy

explicit maps

5. Refer to the exhibit.

A network operator wants to expand the segment routing global block in upcoming maintenance. The operator must ensure that the changes to the segment routing global block have no adverse impacts on the prefix-sid associated with the loopback0 interface used within the OSPF domain.

Which command can the operator use to enforce R2 to have a strict prefix-sid assignment to loopback0?

A)

Option A

Option B

Option C

Option D

6. Which command is used to enable BIDIR-PIM under global configuration mode for Cisco IOS XE Software?

ip pim bidir ip

multicast-routing

ipv4 pim bidir-enable

Ip pim bidlr-enable

7. Refer to the exhibit.

Which LSA type is indicated by this router output?

type 3 LSA

type 4 LSA

type 1 LSA

type 2 LSA

8. Refer to the exhibit.

A service provider technician is working on a multicast issue for a customer. While checking the multicast table, the technician notices that no flags are present for the (1.1.1.1, 239.1.1.1) entry, yet flags are present for the (1.1.1.1, 232.1.1.1) entry.

Which factor might explain this issue?

Only the administratively scoped range is permitted

Only ASM is permitted

Only the default SSM range is permitted

Only GLOP is permitted

9. DRAG DROP

Compare different features between OSPFv2 and OSPFv3.

Drag and drop the descriptions of OSPF from the left onto the correct OSPF versions on the right.

10. After you change the IP address on an IOS XR router, you cannot ping the new address.

Which step did you forget to complete?

commit the configuration

roll back the configuration

merge the configuration

save the running configuration

Page 2 of 3

11. Refer to the exhibit.

Router 1 has established an SR-TE tunnel with router 2.

Which statement describes this configuration?

Router 1 has a list of labels used to explicitly lay out a path to router 2.

Router 1 and router 2 have a bidirectional tunnel set up with dynamic path selection.

Router 1 is the head-end tunnel and has dynamically chosen a path to router 2.

Router 2 is the head-end tunnel and has explicitly set a path to router 1.

12. After an engineer configures BGP in R1, it starts receiving this message

*Jun 29 13:30:50.122: %BGP-5-ADJCHANGE: neighbor 192.168.10.1 Down User reset

Jun 29 13:30:52.341: %BGP-3-NOTIFICATION: sent to neighbor 192.168.10.1 2/6 (unacceptable hold time) 0 bytes

Which action makes the peering come back up again?

Make a soft reset to the peer.

Set up a minimum hold-down timer higher.

Set up a hello timer higher.

Set up a hold-down timer higher.

13. Which two statements about mapping multicast IP addresses to MAC addresses are true? (Choose two.)

All mapped multicast MAC addresses begin with 0x0100.5E

The router performs the mapping before it hands the packet off to a switch

All multicast MAC addresses end with 0x0100.5E

The mapping process may generate overlapping addresses, which can cause receivers to receive unwanted packets

All destination MAC addresses begin with an octet of binary 1s

14. Refer to the exhibit.

An engineer has successfully fixed BGP peering issue. R1 has an established eBGP peering with R2 and R3.

Which mechanism should the engineer apply in order to steer the traffic correctly?

The MED attribute can be applied on R2 to influence R1 to use it as the primary path.

The local preference attribute can be applied on R3 to influence AS 65513 to use AS 65515 as the secondary path.

The weight attribute can be applied on R2 to influence AS 65513 to use AS 65515 as the primary path.

The IGP metric can be manipulated on R1 to allow traffic to be load balanced between R2 and R3.

15. Refer to the exhibit.

How are packets directed through the data plane when SRv6 is implemented?

An ordered list of segments is encoded in a routing extension header

The MPLS data plane is used to push labels onto IGP routes

A stack of labels represents an ordered list of segments

The packet is encapsulated with a header and trailer encoding the ordered list of segments

16. Which two statements about route reflectors are true? (Choose two.)

Routes received from nonclient peers are reflected to route reflector clients as well as nonclient peers.

Routes received from nonclient peers are reflected to route reflector cluster as well as OSPF peers.

If a router received an iBGP route with the originator-ID attribute set to its own router ID, the route is discarded.

Routes received from a route reflector client is reflected to other clients and nonclient peers.

If a route reflector receives a route with a cluster-list attribute containing a different cluster ID, the route is discarded.

17. Refer to the exhibit.

Which task must you perform on interface g1/0/0 to complete the SSM implementation?

configure OSPFv3

enable CDP

disable IGMP

configure IGMPv3

18. A network engineer is troubleshooting OSPF multiareA.

Which Cisco IOS XR feature should the engineer use in order to streamline OSPF issue?

hierarchical CLI

DR support for topology management

routing process enabled by default on all interfaces

show ip ospf topology command

19. An engineer is troubleshooting a connectivity issue across the MPLS network and is verifying the forwarding behavior of packets.

Which table does the engineer look at to verify the forwarding behavior of an IP packet as it enters the MPLS network at the ingress LSR?

LFIB

LIB

RIB

FIB

20. Refer to the exhibit.

An engineer has configured all routers in the environment to run IS-IS Level 1 and Level 2 routing. The engineer wants traffic from R1 to R5 to pass via R2. but IS-IS routing has calculated the best path via R4.

Which action corrects the problem?

Configure routers R1, R4, and R5 for Level 2 routing only.

Set the link metric for the link from router R1 to router R4 to 30 or more.

Set the link metric on R2 for the links from router R2 to routers R3 and R4 to 30 or more.

Configure routers R1, R2, and R5 for Level 1 routing only.

Page 3 of 3

21. Which two characteristics unique to SSM when compared to ASM are true? (Choose two.)

It uses SPT switchover

It uses (*,G) exclusively

It uses IGMPv3

It uses RP

It uses (S,G) exclusively

22. Refer to the exhibit.

A network operator is working to filter routes from being advertised that are covered under an aggregate announcement. The receiving router of the aggregate announcement block is still getting some of the more specific routes plus the aggregate.

Which configuration change ensures that only the aggregate is announced now and in the future if other networks are to be added?

Configure the summary-only keyword on the aggregate command

Set each specific route in the AGGRO policy to drop instead of suppress-route

Filter the routes on the receiving router

Set each specific route in the AGGRO policy to remove instead of suppress-route

23. Refer to the exhibit.

Router 1 has attempted to establish a Cisco MPLS TE tunnel to router 2, but the tunnel has failed.

Which statement about this configuration is true?

Router 1 must define an explicit path to router 2

Router 1 and router 2 must define the RSVP bandwidth reserved on the physical interfaces

Router 2 must have a tunnel interface created with router 1 as the destination

Router 1 must have Cisco MPLS TE enabled on interface gigabitethernet0/1

24. Refer to the exhibit.

Why is neighbor 10.1.5.5 stuck in “2WAY” state?

Router ID 10.1.5.5 is not reachable from R2

OSPF authentication has failed between R2 and 10.1.5.5

It is an expected behavior when OSPF network type is broadcast

OSPF parameters (Area ID or hello interval) are mismatched between R2 and 10.1.5.5

25. Refer to the exhibit.

XR1 and XR2 are sending the prefix 10.11.11.0/24 to XR3. A configured policy on XR1 is incorrectly prepending AS path 11 11 12 12 onto this prefix. A network operator wants to add a policy onto XR3 that will not allow the falsely prepending prefix from being installed.

Which policy configuration applied to the XR3 neighbor configuration for XR1 can accomplish this requirement without impact to other or future received routes?

A)
